2-Way Flat Tee Fitting for West Coast Style Frame Tents
Beyond Tent's technical team stocks this 2-way flat tee as a simple, reliable 90-degree connector for West Coast style frame tent systems. It's the fitting crews reach for when a clean right-angle joint is needed — corner assemblies, banner frames, or custom perimeter sections — without the added connection points of a larger crown or tee.
Fits standard West Coast style frames from most major manufacturers.
Why This Fitting Matters
Not every joint in a custom frame build needs multiple connection points — sometimes a tight, simple 90-degree corner is exactly what the layout calls for. This flat tee gives crews that clean right-angle connection with pin holes on both protrusions, so tubing seats securely without the bulk of a fitting built for more complex intersections.
| Spec |
Detail |
| Material |
1.25" Schedule 40 steel pipe, zinc-plated finish |
| Outside Diameter |
1.656" |
| Inside Diameter |
1.38" |
| Wall Thickness |
0.14" |
| Tensile Strength |
45,000 PSI |
| Connection Type |
Two-way, 90-degree |
| Weight |
3.0 lbs |
| Compatibility |
West Coast style Classic Frame tent systems |
| Shipping Method |
Ships ground |
| SKU |
1C-51303 |
Installation Notes from Our Install Crews
Align the connection holes before forcing tubing onto either protrusion — this fitting is sized for a snug fit, and forcing a misaligned tube can bind the pin holes. Confirm the 90-degree angle matches your layout before pinning, since this fitting doesn't adjust once secured.
